EvoNet-Industry-4-0-Interface

EvoNet-Industry-4-0-Interface - v2.0.1

Documentation / v1.0.0.7 / 15.03.2023 / 15:26

Info

The EvoNet Industry 4.0 Interface is started automatically when the machine computer is started. This start is independent of the EvoNet software.

First of all, it must be ensured that the querying computer is in the same IP area as the EvoNet Industry 4.0 Interface Server. In this case it would be the machine computer. Execute a query in the following format via the RestAPI:
http://*IP.ADRESS.OF.MACHINECOMPUTER*:3333/clients

Here is an example:
http://192.168.3.189:3333/clients

With the help of this JSON data array you can read out the id of the desired client.
Here is an example:

[
    {
        "Id": "4C4C4544-004C-3010-8035-C6C04F475132",
        "Maschinennummer": "9999",
        "Standortinfo": "DELL-OPTIPLEX-1",
        "MaschinenModel": {
            "evoNetEnumValue": 1,
            "evoNetEnumText": "_EVO_BINGO2",
            "maschinenTyp": "EVO BINGO 2",
        }
    }
]

how to get the `data` of a specific client by the client-id?

Execute a query in the following format via the RestAPI:
http://*IP.ADRESS.OF.MACHINECOMPUTER:3333/materialconsumption/json?clientId= UNIVERSALLY-UNIQUE-IDENTIFIER-OF-CLIENT*

Here is an example #1:
http://192.168.3.189:3333/materialconsumption/json?clientId=4C4C4544-004C-3010-8035-C6C04F475132

Here is an example #2 (with optional options):
http://192.168.3.189:3333/materialconsumption/json?clientId=4C4C4544-004C-3010-8035-C6C04F475132&limit=10&withJobImage=false

This will get you JSON data array like the following example based on the main Interface ISquareMeterCounter *:

[
    {
      "_id": "e74f75eb7049a8e08908d8a125081d26",
      "_rev": "1-496d0fe5b7cef043d5e14f025356207f",
      "timeStamp": 1678877246190,
      "clientId": "03000200-0400-0500-0006-000700080009",
      "jobId": "45618e3e-dd9a-464c-af32-9c64ba58eb4f",
      "jobName": "test job xyz",
      "jobImage": null,
      "jobSquareMetersTotal": 202493247.78,
      "jobSquareMetersCutted": 193381051.58,
      "jobSquareMetersCuttedPercentage": 95.5,
      "sheetInfo": {
        "id": "05a1d05b-2698-45bf-9ab3-94d0075255d2",
        "number": 0,
        "name": "Aluminium",
        "thickness": 0.8,
        "width": 1000
      },
      "sheetSectionInfo": {
        "sheetIndex": 23,
        "sectionNumber": 8,
        "sectionSquareMeters": 1012466.2889184328,
        "startTimeStamp": 0,
        "endTimeStamp": 638144740461864700,
        "duration": 64708,
        "result": 0,
        "sheetSquareMetersTotal": 8099729.91,
        "sheetSquareMetersCutted": 7087263.62,
        "sheetSquareMetersCuttedPercentage": 87.5
      },
      "partSegmentInfo": [
        {
          "partId": "b0b756be-5e57-4865-ae97-3727873a38f4",
          "segmentId": "08ef45e4-163b-4abb-b333-13b0e9097331",
          "segmentIndex": 4,
          "segmentLabel": "1-300/300-S4",
          "segmentLabelCustomer": "1.4",
          "numberOfHoles": 48,
          "numberOfContours": 54
        }
      ],
      "programInfo": {
        "fileName": "45618e3e-dd9a-464c-af32-9c64ba58eb4f_23.Nc",
        "programType": 2,
        "programState": 2
      }
    },
    { ... },
    { ... },
    { ... },
    { ... },
]

Attention: All data older than 60 days will be removed automatically. In plain language this means: The end user of this interface is responsible for archiving the data!

how to get the `job list` from the `database` of a specific client by the client-id?

Execute a query in the following format via the RestAPI:
http://*IP.ADRESS.OF.MACHINECOMPUTER:3333/jobs/json?clientId= UNIVERSALLY-UNIQUE-IDENTIFIER-OF-CLIENT*

Here is an example #1:
http://192.168.3.189:3333/jobs/json?clientId=4C4C4544-004C-3010-8035-C6C04F475132

Here is an example #2 (with optional options):
http://192.168.3.189:3333/jobs/json?clientId=4C4C4544-004C-3010-8035-C6C04F475132&afterThisLastChangeDate=1606827150039&withJobImage=false&beautify=false

This will get you JSON data array like the following example based on the main Interface IJobs *:

[
    {
      "id": "45618E3E-DD9A-464C-AF32-9C64BA58EB4F",
      "name": "test job xyz",
      "note": "---",
      "sheetId": "05A1D05B-2698-45BF-9AB3-94D0075255D2",
      "sheetThickness": 0.8,
      "sheetWidth": 1000,
      "creationDate": 1678875042107,
      "lastChangeDate": 1678875384083,
      "startDate": 1678838400000,
      "endDate": 1678838400000
    },
    {
      "id": "02EA8C52-7D89-45C0-9DD0-B0E1D79EAFB7",
      "name": "2023_01_25_12_07_13",
      "note": "---",
      "sheetId": "F798F0B7-14E3-4B54-9FF9-CA8AA4A6C844",
      "sheetThickness": 0.6,
      "sheetWidth": 1000,
      "creationDate": 1674640405120,
      "lastChangeDate": 1676457275078,
      "startDate": 1674604800000,
      "endDate": 1674604800000
    },
    { ... },
    { ... },
    { ... },
    { ... },
]

how to get the `job list` from the `exported job files` of the specific `folder on drive c:\`?

Execute a query in the following format via the RestAPI:
http://*IP.ADRESS.OF.MACHINECOMPUTER:3333/jobs/production?productionFolder= C:\SHARED-FOLDER-PATH*

Here are some examples #1:
http://192.168.3.189:3333/jobs/production?productionFolder=C:\EvoNetJobs\07-09
http://192.168.3.189:3333/jobs/production?productionFolder=C:\OneDrive\EvoNet\Jobs\Production
http://192.168.3.189:3333/jobs/production?productionFolder=C:\ExportedJobs\third-quarter

Here is an example #2 (with Microsoft-OneDrive and optional options):
http://192.168.3.189:3333/jobs/production?productionFolder=C:\OneDrive\EvoNet\Jobs\Production&afterThisLastChangeDate=1606827150039&withJobImage=false&beautify=false

This will get you JSON data array like the following example based on the main Interface IJobFile *:

[
  {
    "jobFileInfo": {
      "jobFileDirectory": "C:\\OneDrive\\EvoNet\\Jobs\\Production",
      "jobFileName": "2019_03_07_10_48_01",
      "jobFileExtension": ".EvoNet_Exported_Auftrag"
    },
    "job": {
      "id": "546671ae-06cd-4cd7-87ca-4ba9698abf53",
      "name": "2019_03_07_10_48_01",
      "note": "",
      "sheetId": "f798f0b7-14e3-4b54-9ff9-ca8aa4a6c844",
      "sheetThickness": "0.60",
      "sheetWidth": "1000",
      "creationDate": 1551951097077,
      "lastChangeDate": 1631521615081,
      "startDate": 1551913200000,
      "endDate": 1551913200000,
      "jobImage": null
    }
  },
  {
    "jobFileInfo": {
      "jobFileDirectory": "C:\\OneDrive\\EvoNet\\Jobs\\Production",
      "jobFileName": "2020_10_06_12_16_06",
      "jobFileExtension": ".EvoNet_Exported_Auftrag"
    },
    "job": {
      "id": "426d5c07-bc57-49a9-b7d6-1f53bfcef568",
      "name": "2020_10_06_12_16_06",
      "note": "---",
      "sheetId": "f798f0b7-14e3-4b54-9ff9-ca8aa4a6c844",
      "sheetThickness": "0.60",
      "sheetWidth": "1000",
      "creationDate": 1600345309430,
      "lastChangeDate": 1631521343033,
      "startDate": 1600293600000,
      "endDate": 1600293600000,
      "jobImage": null
    }
  }
]

how to post the `external sorted job list` of the `exported job files` to the of the specific `client`?

Execute a post in the following format via the RestAPI:
post http://*IP.ADRESS.OF.MACHINECOMPUTER:3333/jobs/production/order?clientId= UNIVERSALLY-UNIQUE-IDENTIFIER-OF-CLIENT*
content-type: application/json
[] (JSON data array like the following example based on the main Interface IJobFile)

Here is an example:

post http://192.168.3.189:3333/jobs/production/order?clientId=4C4C4544-004C-3010-8035-C6C04F475132
content-type: application/json

[
  {
    "jobFileInfo": {
      "jobFileDirectory": "C:\\OneDrive\\EvoNet\\Jobs\\Production",
      "jobFileName": "2019_03_07_10_48_01",
      "jobFileExtension": ".EvoNet_Exported_Auftrag"
    },
    "job": {
      "id": "546671ae-06cd-4cd7-87ca-4ba9698abf53",
      "name": "2019_03_07_10_48_01",
      "note": "",
      "sheetId": "f798f0b7-14e3-4b54-9ff9-ca8aa4a6c844",
      "sheetThickness": "0.60",
      "sheetWidth": "1000",
      "creationDate": 1551951097077,
      "lastChangeDate": 1631521615081,
      "startDate": 1551913200000,
      "endDate": 1551913200000,
      "jobImage": null
    }
  },
  {
    "jobFileInfo": {
      "jobFileDirectory": "C:\\OneDrive\\EvoNet\\Jobs\\Production",
      "jobFileName": "2020_10_06_12_16_06",
      "jobFileExtension": ".EvoNet_Exported_Auftrag"
    },
    "job": {
      "id": "426d5c07-bc57-49a9-b7d6-1f53bfcef568",
      "name": "2020_10_06_12_16_06",
      "note": "---",
      "sheetId": "f798f0b7-14e3-4b54-9ff9-ca8aa4a6c844",
      "sheetThickness": "0.60",
      "sheetWidth": "1000",
      "creationDate": 1600345309430,
      "lastChangeDate": 1631521343033,
      "startDate": 1600293600000,
      "endDate": 1600293600000,
      "jobImage": null
    }
  }
]

*For more details, please refer to the interface descriptions on the top right...
contact: hotline@mabi.ch

Changelog

v1.0.1

new parameters for /materialconsumption/json?clientId=4C.....32&limit=10&withJobImage=false

limit get only the last n records (default = 9999 optional)

withJobImage get the jobImage oder not (default = false optional)

v1.0.2

new route for /jobs/json?clientId=4C.....32&afterThisLastChangeDate=1606827150039&withJobImage=false&beautify=false

afterThisLastChangeDate get only jobs with last changes after this timestamp (number of milliseconds since 1970/01/01 optional)

withJobImage get the jobImage oder not (default = false optional)

beautify does beautify the json result (default = false optional)

removal of the following unnecessary parameters:

sheetSectionInfo.startTimeStamp (please use ISquareMeterCounter.timestamp)

sheetSectionInfo.endTimeStamp (please use ISheetSectionInfo.duration)

deployment completely rewritten due to a change of container platform

v1.0.3 (obsolete!)

new GET route for /jobs/production?productionFolder=P:\EvoNet-Production&afterThisLastChangeDate=1606827150039&withJobImage=false&beautify=false

productionFolder define the shared folder which contains the exported job files.required)

**note:if the share is on a local or external server like \\server1\share1 you have to mount this as a **local drive letter** (A-Z)!)

afterThisLastChangeDate get only jobs with last changes after this timestamp (number of milliseconds since 1970/01/01 optional)

withJobImage get the jobImage oder not (default = false optional)

beautify does beautify the json result (default = false optional)

new POST route for /jobs/production/order?clientId=4C.....32

v1.0.4

new GET route for /jobs/production?productionFolder=C:\OneDrive\EvoNet\Jobs\Production&afterThisLastChangeDate=1606827150039&withJobImage=false&beautify=false

productionFolder define the local windows folder which contains the exported job files. required

**note:the folder root location must be on **drive c:**)

**hint:**We recommend using Microsoft-OneDrive to synchronize the data**

afterThisLastChangeDate get only jobs with last changes after this timestamp (number of milliseconds since 1970/01/01 optional)

withJobImage get the jobImage oder not (default = false optional)

beautify does beautify the json result (default = false optional)

new POST route for /jobs/production/order?clientId=4C.....32

v2.0.1

new properties in ISquareMeterCounter

jobSquareMetersTotal details see (ISquareMeterCounter.jobSquareMetersTotal)

jobSquareMetersCutted details see (ISquareMeterCounter.jobSquareMetersCutted)

jobSquareMetersCuttedPercentage details see (ISquareMeterCounter.jobSquareMetersCuttedPercentage)

new properties in ISheetSectionInfo

sheetSquareMetersTotal details see (ISheetSectionInfo.sheetSquareMetersTotal)

sheetSquareMetersCutted details see (ISheetSectionInfo.sheetSquareMetersCutted)

sheetSquareMetersCuttedPercentage details see (ISheetSectionInfo.sheetSquareMetersCuttedPercentage)

cuts and rounded parts now have the same logic like flat parts
details see (ISheetSectionInfo)

changed properties indexes in ISheetSectionInfo (details see drawing below)

sheetIndex now starts from index 0 (before from index 1)
details see (ISheetSectionInfo.sheetIndex)

sectionNumber now starts from index 1 (before from index 0)
details see (ISheetSectionInfo.sectionNumber)
